| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
9 pcs
|
9 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Material | |
| Cable End Type | |
| Connector | |
| Contact Finish | |
| Contact Material | |
| FFC, FCB Thickness | |
| Features | |
| Flat Flex Type | |
| Height Above Board | |
| Housing Material | |
| Locking Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The FH12-24S-0.5SVA(54) is a 24-position, 0.5mm pitch FFC/FPC connector from Hirose Electric. It features a vertical orientation with one-sided contacts, ideal for space-constrained applications. The connector uses surface mount termination with solder retention, ensuring reliable board attachment. It incorporates a flip lock mechanism for zero insertion force (ZIF) operation, simplifying cable insertion and providing strain relief. The housing is made of UL94 V-0 rated polyamide (nylon) and the actuator is polyphenylene sulfide (PPS). Contacts are gold-plated phosphor bronze, offering good conductivity and corrosion resistance. The connector is rated for 50V and operates over -40°C to 85°C. It is compatible with 0.30mm thick FFC/FPC cables. The mounting height above board is 3.60mm.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.39 | $2.39 |
| 10+ | $2.04 | $2.04 |
| 25+ | $1.82 | $1.82 |
| 100+ | $1.73 | $1.73 |
| 250+ | $1.61 | $1.61 |
| 500+ | $1.52 | $1.52 |
| 1,000+ | $1.40 | $1.40 |
| 2,000+ | $1.38 | $1.38 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
24 positions.
0.5mm (0.020 inches).
50V.
Surface mount (SMT).
-40°C to 85°C.
Yes, it has a flip lock mechanism.
Gold.
