| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4,000 pcs
|
4000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Finish | |
| Length | |
| Thread Size |
The FH-632-5ZI from PennEngineering is a self-clinching threaded stud, part of the FH/FHS/FHA series. This component is engineered for permanent fastening in sheet metal applications where a reliable internal thread is required.
Key specifications include a #6-32 thread size (0.138-32, 2A ASME B1.1) and a hardened carbon steel construction for durability. The stud is finished with colorless zinc plating (SC1, Type III per ASTM B633) for corrosion resistance. It is designed for use in sheet materials with a hardness of HRB 80 / HB 150 or less.
The FH-632-5ZI has a stud height of 0.206 inches and a length of 0.312 inches. The required hole size in the sheet is 0.137 inches, with a minimum edge distance of 0.25 inches from the hole centerline to the panel edge and a maximum edge distance of 0.09 inches. This stud utilizes self-clinching technology for secure mounting.
This component is suitable for various industrial applications requiring robust threaded connections in thin sheet metal. Its design ensures a flush installation on the opposite side of the sheet, providing a clean finish.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.20 | $1.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The thread size is #6-32 (0.138-32).
The stud is made from hardened carbon steel.
The finish is colorless zinc plated, SC1 (5µm), Type III per ASTM B633.
It is designed for use in sheet hardness HRB 80 / HB 150 or less.
The required hole size in the sheet is 0.137 inches.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
