| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
112 pcs
|
112 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable Diameter | |
| Cable Opening | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Contact Resistance | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Gender | |
| Impedance | |
| Ingress Protection | |
| Insulator Material | |
| Lead Style | |
| Material Flammability Rating | |
| Mating Cycles | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Orientation | |
| Primary Material | |
| Shell Finish | |
| Shell Material | |
| Shell Size | |
| Shell Style | |
| Shielding | |
| Storage Temperature | |
| Termination | |
| Termination Style | |
| Weight |
The Lemo FGG.2B.810.CLAD72Z is a circular connector plug from the Series B indoor keyed family. It features 11 positions comprising 10 low voltage contacts and 1 coax contact (50 Ohm), with male pins. The plug is free hanging (in-line) and uses a push-pull locking mechanism for quick, secure mating.
Key electrical specifications include a current rating of 7A, impedance of 50 Ohms, test voltage of 1.35 kV DC, and maximum contact resistance of 5.8 mOhm. The connector is fully shielded, providing minimum 75 dB attenuation at 10 MHz and 40 dB at 1 GHz. It is rated IP50 for dust protection and operates from -55°C to 250°C.
Low voltage contacts are terminated via solder cup, while the coax contact uses crimp termination for both conductor and screen. The plug accepts cable diameters from 6.30 mm to 7.20 mm and wire sizes 30 to 22 AWG. The shell is brass with chrome plating, and the insulator is PEEK (UL94 V-0). With 5000 mating cycles, 100g shock resistance, and over 1000 hours salt spray resistance, this connector is designed for harsh environments.
| Qty | Low | High |
|---|---|---|
| 10+ | $101.04 | $101.04 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
11 positions (10 low voltage + 1 coax).
7 A.
1.35 kV DC.
Free Hanging (In-Line).
50 Ohms.
-55°C to 250°C.
75 dB at 10 MHz and 40 dB at 1 GHz.
