FDP22N50N N-Channel MOSFET rated for 500V drain-source voltage and 22A continuous current. Packaged in a TO-220-3 through-hole package.
Mfr Part #:

FDP22N50N

Available from 1 distributors
Mfr Name: On Semiconductor
On Semiconductor
N-Channel MOSFET rated for 500V drain-source voltage and 22A continuous current. Packaged in a TO-220-3 through-hole package.
✓ Total Stock: 4,020 pcs
$ Price Range: $2.75 - $5.71

FDP22N50N Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Optech Co.,Limited ✓
Non-Authorised Inventory information
4,020 pcs
On Request
4020 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

FDP22N50N Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Drain to Source Voltage (Vdss)
Drive Voltage (Max Rds On, Min Rds On)
FET Type
Gate Charge (Qg) (Max) @ Vgs
Input Capacitance (Ciss) (Max) @ Vds
Lead Spacing
Lead Style
Mounting Type
Operating Temperature
Power Dissipation (Max)
Rds On (Max) @ Id, Vgs
SVHC Present
Storage Temperature
Supplier Device Package
Tape & Reel
Technology
Vgs (Max)
Vgs(th) (Max) @ Id
View Similar Products (0)

FDP22N50N Description

Short technical summary and product information.

The FDP22N50N is an N-Channel MOSFET from On Semiconductor's UniFET II family, based on advanced planar stripe and DMOS technology. It features a maximum drain-source voltage of 500V and continuous drain current of 22A at 25°C. The device offers low on-resistance (185 mOhm typical at Vgs=10V), low gate charge (49 nC typical), and low reverse transfer capacitance (24 pF) for efficient switching performance. It is 100% avalanche tested with a single pulse avalanche energy rating of 1000 mJ. The MOSFET is suitable for switching power converter applications such as power factor correction (PFC), flat panel display TV power supplies, ATX power supplies, and electronic lamp ballasts. It is RoHS compliant and comes in a TO-220-3 through-hole package with a standard package quantity of 1000 units per tube.

FDP22N50N Quick Information

Product Type: MOSFET
Series: UniFET II
Canonical Name: FDP22N50N N-Channel MOSFET
Subcategory: Single MOSFET

FDP22N50N Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

FDP22N50N Estimated Pricing

Qty Low High
1+ $5.71 $5.71
10+ $3.74 $3.74
100+ $2.75 $2.75

Estimated market price range - modelled values for guidance only, not live distributor offers.

FDP22N50N Features

  • N-Channel MOSFET with 500V drain-source voltage rating.
  • Low on-resistance of 185 mOhm typical at 10V gate drive.
  • Low gate charge of 49 nC typical for efficient switching.
  • 100% avalanche tested for ruggedness.
  • RoHS compliant and MSL 1 unlimited.

FDP22N50N Applications

  • Used in power factor correction (PFC) circuits.
  • Ideal for flat panel display TV power supplies.
  • Suitable for ATX power supplies.
  • Used in electronic lamp ballasts.
  • Applicable in uninterruptible power supplies.

FDP22N50N FAQs

7 frequently asked questions generated from this part’s specifications.
What is the drain-source voltage rating of the FDP22N50N?

500V maximum.

What package does the FDP22N50N come in?

TO-220-3 through-hole package.

What is the operating temperature range?

-55°C to 150°C junction temperature.

Is the FDP22N50N RoHS compliant?

Yes, RoHS3 compliant (unverified).

What is the continuous drain current at 25°C?

22A.

What is the typical on-resistance?

185 mOhm at Vgs=10V, Id=11A.

What is the gate threshold voltage?

5V maximum at Id=250µA.
