| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
186,400 pcs
|
186400 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Drain to Source Voltage (Vdss) | |
| Drive Voltage (Max Rds On, Min Rds On) | |
| FET Type | |
| Gate Charge (Qg) (Max) @ Vgs | |
| Input Capacitance (Ciss) (Max) @ Vds | |
| Mounting Type | |
| Operating Temperature | |
| Power Dissipation (Max) | |
| Rds On (Max) @ Id, Vgs | |
| Supplier Device Package | |
| Tape & Reel | |
| Technology | |
| Vgs (Max) | |
| Vgs(th) (Max) @ Id |
This N-Channel MOSFET is produced using onsemi's advanced POWERTRENCH process, designed to minimize on-state resistance while maintaining superior switching performance.
Key electrical specifications include a drain-source voltage of 100V, continuous drain current of 120A (package limited; silicon limited to 164A), pulsed drain current of 656A, maximum on-resistance of 4.5mOhm at 10V gate drive, gate charge of 74nC max, and input capacitance of 5270pF at 50V.
Applications include synchronous rectification in ATX/server/telecom power supplies, battery protection circuits, motor drives, uninterruptible power supplies, and micro solar inverters.
The device is packaged in a TO-220-3 through-hole package, supplied in tubes of 50, with an operating temperature range of -55°C to 175°C. It is RoHS compliant.
| Qty | Low | High |
|---|---|---|
| 1+ | $5.22 | $5.22 |
| 10+ | $2.78 | $2.78 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
100 V.
TO-220-3, through-hole mounting.
-55°C to 175°C (junction).
Yes, RoHS3 compliant per datasheet.
120 A at 25°C (package limited); silicon limited to 164 A.
3.8 mOhm typical at Vgs=10V, Id=100A; maximum 4.5 mOhm.
74 nC maximum at Vgs=10V; typical 54 nC.
