| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| SVHC Present | |
| Storage Temperature | |
| Type | |
| Voltage | |
| Width |
The Bel Power Solutions FCP400-12G is a highly-efficient AC-DC power supply designed for various applications. It offers a single high-current output of 12V at 40A, with a total rated power of 400W. The unit accepts a wide input voltage range from 90 to 264 VAC, making it suitable for global use.
Key features include an I2C interface for communication, active current sharing, and an included ORing FET for redundant and hot-swap applications. It also boasts a high-efficiency topology, certified to 80 PLUS Platinum standards, and meets safety standards such as CSA/UL60950-1, EN60950-1, and IEC60950-1. The power supply is designed for rack mounting and has a compact cassette form factor.
This converter is suitable for ITE (Commercial) applications and provides overtemperature, output overvoltage, and output overcurrent protection. Its design prioritizes high density and efficient operation, with a focus on low conducted and radiated EMI, meeting EN 55022 class B standards.
The input voltage range is 90-264 VAC continuous, with a transient rating of 300 VAC for 60 ms.
The operating temperature range is 0°C to 55°C ambient with internal fan cooling.
The main output is 12 VDC with a maximum current of 33.3 A, and there is a standby output of 0.7 A.
The efficiency is 90% at 230 VAC input and nominal load.
The hold-up time is at least 20 ms starting at 230 VAC input and nominal power.
The power factor is 0.96 at nominal input voltage and nominal load.
The dimensions are 215.9mm (8.50") length, 101.6mm (4.00") width, and 41.9mm (1.65") height.
