F6QA1G581M2QZ-X The Taiyo Yuden F6QA1G581M2QZ-X is a SAW filter operating at a center frequency of 1.95GHz. It features a bandwidth of 60MHz and a maximum insertion loss of 1.8dB.
Mfr Part #:

F6QA1G581M2QZ-X

Available from 1 distributors
Mfr Name: Taiyo Yuden
Taiyo Yuden
The Taiyo Yuden F6QA1G581M2QZ-X is a SAW filter operating at a center frequency of 1.95GHz. It features a bandwidth of 60MHz and a maximum insertion loss of 1.8dB.
✓ Total Stock: 6,098 pcs
$ Price Range: $0.10

F6QA1G581M2QZ-X Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Rayichip ✓
Non-Authorised Inventory information
6,098 pcs
On Request
6098 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

F6QA1G581M2QZ-X Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Bandwidth
Frequency (Center
Height
Industrial Grade
Insertion Loss
Medical Grade
Military Grade
Mounting Type
Storage Temperature
Tape & Reel
View Similar Products (0)

F6QA1G581M2QZ-X Description

Short technical summary and product information.

This Taiyo Yuden F6QA1G581M2QZ-X is a Surface Acoustic Wave (SAW) filter designed for high-frequency applications. It operates at a center frequency of 1.95GHz with a bandwidth of 60MHz, making it suitable for cellular and LTE communication systems.



The filter exhibits a maximum insertion loss of 1.8dB, ensuring signal integrity. It is housed in a compact 5-SMD, No Lead package with dimensions of 1.10mm x 0.90mm and a maximum height of 0.50mm. The surface mountable design facilitates integration into various electronic circuits.



Applications for this SAW filter include cellular, LTE, and WCDMA systems. Its robust construction and precise specifications make it a reliable component for signal processing in modern wireless devices.

F6QA1G581M2QZ-X Quick Information

Product Type: SAW Filter
Canonical Name: SAW Filter
Subcategory: SAW Filter

F6QA1G581M2QZ-X Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

F6QA1G581M2QZ-X Estimated Pricing

Qty Low High
1+ $0.10 $0.10

Estimated market price range - modelled values for guidance only, not live distributor offers.

F6QA1G581M2QZ-X Features

  • SAW filter with 1.95GHz center frequency.
  • Features a 60MHz bandwidth for signal processing.
  • Maximum insertion loss of 1.8dB.
  • Compact 1.10mm x 0.90mm surface mount package.
  • Suitable for cellular and LTE applications.

F6QA1G581M2QZ-X Applications

  • Used in cellular communication systems.
  • Ideal for LTE signal filtering.
  • Applicable to WCDMA devices.
  • Suitable for RF signal processing.

F6QA1G581M2QZ-X FAQs

6 frequently asked questions generated from this part’s specifications.
What is the center frequency of the F6QA1G581M2QZ-X SAW filter?

The center frequency is 1.95GHz.

What is the bandwidth of this SAW filter?

The bandwidth is 60MHz.

What is the maximum insertion loss for the F6QA1G581M2QZ-X?

The maximum insertion loss is 1.8dB.

What are the dimensions of the F6QA1G581M2QZ-X SAW filter?

The dimensions are 1.10mm x 0.90mm.

What is the mounting type for this Taiyo Yuden SAW filter?

The mounting type is Surface Mount.

What package type does the F6QA1G581M2QZ-X come in?

It comes in a 5-SMD, No Lead package, supplied on Tape & Reel (TR).
