| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Stability | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage |
This SL Power Electronics F15-15-A+ is a linear AC/DC converter designed for ITE (Commercial) applications. It provides a single output with a current rating of 15A and a power output of 225W, operating from a universal input voltage range of 100 to 240 VAC.
Key features include adjustable output voltage, remote sense capability, and automatic current limit/foldback for short circuit protection. The unit is chassis mountable and operates within a temperature range of 0°C to 70°C with derating. Stability is rated at ±0.05% for 24 hours after warmup, with a temperature coefficient of ±0.01%/°C maximum.
Compliance includes CE, cURus, and TUV approvals. The transformer insulation meets Class F (155°C) standards, and MTBF is rated at over 200,000 hours per MIL-HDBK-217D for most units.
The F15-15-A+ has an output current of 15 A.
The F15-15-A+ accepts a universal input voltage range of 100 to 240 VAC.
The F15-15-A+ has a power rating of 225W.
The operating temperature range for the F15-15-A+ is 0°C to 70°C with derating.
Yes, the F15-15-A+ features remote sensing.
The F15-15-A+ includes automatic current limit/foldback for short circuit protection and optional overvoltage protection.
