| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
13,965 pcs
|
13965 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
650 pcs
|
650 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
17 pcs
|
17 pcs | On Request | 1 | On Request | On Request | NO DC | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating (Max) | |
| DC Resistance (DCR) (Max) | |
| Filter Type | |
| Height (Max) | |
| Impedance @ Frequency | |
| Length | |
| Mounting Type | |
| Number of Lines | |
| SVHC Present | |
| Tape & Reel | |
| Width |
The Panasonic EXC-CL3225U1 is a chip bead core designed for noise suppression in signal lines. It offers a nominal impedance of 45 Ω at 100 MHz, making it suitable for filtering high-frequency noise in digital and audio equipment.
With a maximum DC resistance of 50 mΩ and a current rating of 2 A, this ferrite bead provides low power loss while handling moderate currents. The component is housed in a standard 1210 (3225 Metric) surface-mount package with dimensions 3.20 mm x 2.50 mm and a maximum height of 1.90 mm.
Typical applications include digital devices such as PCs, printers, HDDs, CD/DVD-ROMs, and audio/video equipment. The bead is RoHS compliant and has an MSL rating of 1 (unlimited).
45 Ω at 100 MHz.
2 A.
50 mΩ maximum.
1210 (3225 Metric).
Yes, RoHS3 compliant.
Surface Mount.
1 line.
