EVAL-SDP-CB1Z The EVAL-SDP-CB1Z is an SDP-B controller board from Analog Devices. It provides USB 2.0 high speed connectivity and is based on the ADSP-BF527 Blackfin processor.
Mfr Part #:

EVAL-SDP-CB1Z

Available from 1 distributors
Mfr Name: Analog Devices / Maxim Integrated
Analog Devices / Maxim Integrated
The EVAL-SDP-CB1Z is an SDP-B controller board from Analog Devices. It provides USB 2.0 high speed connectivity and is based on the ADSP-BF527 Blackfin processor.
✓ Total Stock: 2,002 pcs
$ Price Range: $137.11

EVAL-SDP-CB1Z Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Optech Co.,Limited ✓
Non-Authorised Inventory information
2,002 pcs
On Request
2002 pcs On Request 1 On Request On Request 24+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

EVAL-SDP-CB1Z Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Accessory Type
Connector Type
For Use With
Interface
Medical Grade
Supply Voltage
Tape & Reel
View Similar Products (0)

EVAL-SDP-CB1Z Description

Short technical summary and product information.

The EVAL-SDP-CB1Z (SDP-B) is a controller board within Analog Devices' System Demonstration Platform (SDP). It enables USB 2.0 high speed communication between a PC and evaluation daughter boards.



The board is built around the ADSP-BF527 Blackfin processor and provides two identical 120-pin small footprint connectors for interfacing with daughter boards. It is powered via USB at 5 V.



Designed for use with Analog Devices component evaluation boards and Circuits from the Lab reference circuits, the SDP-B serves as the communication bridge in customer evaluation environments.

EVAL-SDP-CB1Z Quick Information

Product Type: Interface Board
Canonical Name: EVAL-SDP-CB1Z SDP-B Controller Board
Subcategory: Controller Board

EVAL-SDP-CB1Z Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

EVAL-SDP-CB1Z Estimated Pricing

Qty Low High
1+ $137.11 $137.11

Estimated market price range - modelled values for guidance only, not live distributor offers.

EVAL-SDP-CB1Z Features

  • USB 2.0 high speed PC interface.
  • ADSP-BF527 Blackfin processor based.
  • Two 120-pin small footprint connectors.
  • 5 V USB bus powered operation.

EVAL-SDP-CB1Z Applications

  • Evaluation of Analog Devices components and circuits.
  • System demonstration platform controller board.
  • USB communication bridge for daughter boards.

EVAL-SDP-CB1Z FAQs

4 frequently asked questions generated from this part’s specifications.
What is the interface type of the EVAL-SDP-CB1Z?

USB 2.0 High Speed.

What processor does the EVAL-SDP-CB1Z use?

ADSP-BF527 (Blackfin) processor.

What connectors are on the EVAL-SDP-CB1Z?

Two identical 120-pin small footprint connectors.

What is the supply voltage for the EVAL-SDP-CB1Z?

5 V, supplied via USB.
