| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| HI-POT | |
| Height | |
| Input Connector | |
| Input Type | |
| Input Voltage | |
| Insulation Resistance | |
| Length | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Output Current | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| Ripple | |
| Storage Temperature | |
| Voltage | |
| Width |
The CUI Inc. ETS120416UTC-P5P-SZ is a 40W desktop switching power supply designed for ITE (Commercial) applications. It provides a regulated 12V DC output at a maximum current of 4.16A, delivering up to 49.9W of power.
This adapter features universal AC input (90-255V ac) and operates within a frequency range of 47-63 Hz. Key electrical specifications include a line regulation of ±1% and a load regulation of ±5%. It incorporates over-voltage protection and short-circuit protection with auto-restart.
The unit meets EISA and efficiency Level IV regulations, with a no-load power consumption of 0.5W. Safety approvals include UL/cUL, CB, and CE, and it complies with EMI standards FCC Part 15 Class B and CE EN55022/EN55024. The operating temperature range is 0°C to 40°C.
Mechanically, the adapter has dimensions of 97.0mm x 62.0mm x 33.0mm. It utilizes an IEC 320-C6 input connector and a 2.1mm I.D. x 5.5mm O.D. barrel plug output connector with positive center polarization. The cord length is 60.2 inches (1.53m). This product is RoHS3 compliant.
The input voltage range is 90-255V AC at 47-63Hz.
The output is 12V DC at up to 4.16A, providing 49.9W maximum.
It has UL/cUL, CB (IEC60950-1), and CE (GS/TUV EN60950-1) approvals.
The operating temperature range is 0°C to 40°C.
It uses a barrel plug with 2.1mm inner diameter and 5.5mm outer diameter, 9.5mm length, positive center polarity.
Over voltage protection (110-150% of nominal output) and short circuit protection with auto-restart.
