| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,000 pcs
|
3000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
91 pcs
|
91 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Case Type | |
| Current | |
| Dimming | |
| Dimming Range | |
| Dimming Type | |
| Efficiency | |
| Features | |
| Height | |
| IP Rating | |
| Input Voltage (AC) | |
| Length | |
| Lifetime | |
| Max Case Temperature | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Power (Watts) | |
| Power Factor | |
| Protection Features | |
| Ratings | |
| Startup Time | |
| THD (Total Harmonic Distortion) | |
| Termination Style | |
| Topology | |
| Type | |
| Voltage | |
| Width |
The ESS020W-0500-34 is a 17W constant current LED driver from ERP Power, part of the ESS series. It accepts a wide input voltage range of 120 to 277VAC and delivers a constant 500mA output current with an output voltage range of 6 to 56Vdc. The driver achieves up to 87% typical efficiency and supports Tri-Mode Dimming™, including TRIAC (forward-phase), ELV (reverse-phase), and 0-10V analog dimming, with a dimming range of 1 to 100% of output current. Protection features include output open load, over-current, short-circuit (hiccup), and over-temperature with auto recovery. The driver is housed in a plastic IP64-rated case measuring 83.8mm x 39.9mm x 25.1mm (3.30" x 1.57" x 0.99") with wire leads termination. It is designed for use in LED lighting fixtures requiring constant current regulation and flexible dimming control. The operating temperature range is -30°C to 70°C, with a maximum case temperature of 90°C. The driver has a typical lifetime of 50,000 hours at 70°C case hot spot. The driver is compliant with FCC Part 15 Class B (120Vac) and Class A (277Vac), EN55015, and meets ENERGY STAR, DLC, and CA Title 24 requirements. Approvals include CE and cURus. Environmental compliance includes RoHS3 and REACH unaffected.
120 to 277 VAC.
500 mA constant current, output voltage range 6 to 56 Vdc.
TRIAC (forward-phase), ELV (reverse-phase), and 0-10V analog dimming.
-30°C to 70°C.
IP64.
Yes, RoHS3 compliant.
Output open load, over-current, short-circuit (hiccup), and over-temperature with auto recovery.
