ESP8285N08 The Espressif Systems ESP8285N08 is an SMD RF Transceiver IC with integrated MCU. It operates within the 2.4GHz frequency band and supports 802.11b/g/n protocols.
Mfr Part #:

ESP8285N08

Available from 1 distributors
Mfr Name: Espressif Systems
Espressif Systems
The Espressif Systems ESP8285N08 is an SMD RF Transceiver IC with integrated MCU. It operates within the 2.4GHz frequency band and supports 802.11b/g/n protocols.
✓ Total Stock: 1,319 pcs
$ Price Range: $710.26

ESP8285N08 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
1,319 pcs
On Request
1319 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

ESP8285N08 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Data Rate (Max)
Frequency
GPIO
Modulation
Mounting Type
Operating Temperature
Power
Protocol
RF Family
Sensitivity
Serial Interfaces
Supplier Device Package
Tape & Reel
Type
Voltage
View Similar Products (0)

ESP8285N08 Description

Short technical summary and product information.

The Espressif Systems ESP8285N08 is a surface mount RF Transceiver IC that integrates a microcontroller. It operates within the 2.4GHz to 2.483GHz frequency range, supporting 802.11b/g/n Wi-Fi standards.



Key electrical specifications include an operating voltage range of 2.7V to 3.6V, a current draw of 72mA to 73mA, and a maximum data rate of 72.2Mbps. The device offers a sensitivity of -97dBm and a power output of 20dBm. It features multiple serial interfaces such as I²C, SPI, and UART, along with 17 GPIO pins.



This component is housed in a 32-VFQFN Exposed Pad package, measuring 5x5mm (Supplier Device Package), and is designed for surface mounting. The operating temperature range is -40°C to 85°C.

ESP8285N08 Quick Information

Product Type: RF Transceiver IC
Canonical Name: ESP8285N08 RF Transceiver IC
Subcategory: Integrated Circuits (ICs)

ESP8285N08 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

ESP8285N08 Estimated Pricing

Qty Low High
1+ $710.26 $710.26

Estimated market price range - modelled values for guidance only, not live distributor offers.

ESP8285N08 Features

  • Integrated Wi-Fi and MCU functionality.
  • Operates at 2.4GHz frequency band.
  • Supports 802.11b/g/n wireless protocols.
  • Surface mountable 32-VFQFN exposed pad package.
  • Wide operating temperature range of -40°C to 85°C.

ESP8285N08 Applications

  • Ideal for IoT device connectivity.
  • Suitable for wireless sensor networks.
  • Used in smart home automation.
  • Applicable for remote control systems.
  • Enables portable wireless devices.

ESP8285N08 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the operating voltage for the ESP8285N08?

The operating voltage is 2.7V to 3.6V.

What is the operating temperature range of the ESP8285N08?

The operating temperature range is -40°C to 85°C.

What is the maximum data rate for the ESP8285N08?

The maximum data rate is 72.2Mbps.

What package type is the ESP8285N08 available in?

It is available in a 32-VFQFN Exposed Pad package.

Does the ESP8285N08 support Wi-Fi?

Yes, it supports 802.11b/g/n protocols.
