ESP32-U4WDH The Espressif Systems ESP32-U4WDH is a 2.4 GHz Wi-Fi and Bluetooth LE SoC. It features 4MB Flash memory and is housed in a 48-QFN package.
Mfr Part #:

ESP32-U4WDH

Available from 1 distributors
Mfr Name: Espressif Systems
Espressif Systems
The Espressif Systems ESP32-U4WDH is a 2.4 GHz Wi-Fi and Bluetooth LE SoC. It features 4MB Flash memory and is housed in a 48-QFN package.
✓ Total Stock: 1,173 pcs
$ Price Range: $710.26

ESP32-U4WDH Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
1,173 pcs
On Request
1173 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

ESP32-U4WDH Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Frequency
Memory Size
Mounting Type
Power
RF Family
Serial Interfaces
Storage Temperature
Supplier Device Package
Supplier Package
Tape & Reel
Type
View Similar Products (0)

ESP32-U4WDH Description

Short technical summary and product information.

The Espressif Systems ESP32-U4WDH is a versatile System-on-Chip (SoC) designed for wireless communication applications. It integrates both Wi-Fi and Bluetooth LE capabilities, operating in the 2.4 GHz frequency band. This chip is equipped with 4MB of Flash memory, 448kB of ROM, and 520kB of SRAM, providing ample resources for embedded systems.



The ESP32-U4WDH supports various serial interfaces including I²C, I²S, SPI, and UART, facilitating seamless integration with other components. Its RF capabilities include a transmitting power of 19.5 dBm. The SoC is designed for surface mount applications and comes in a compact 48-QFN (5x5) package.



This component is suitable for a wide range of IoT and embedded projects requiring wireless connectivity. Its combination of processing power, memory, and integrated wireless features makes it a robust solution for diverse applications.

ESP32-U4WDH Quick Information

Product Type: RF Transceiver IC
Series: ESP32
Canonical Name: ESP32-U4WDH Wi-Fi + Bluetooth LE SoC
Subcategory: SoC

ESP32-U4WDH Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

ESP32-U4WDH Estimated Pricing

Qty Low High
1+ $710.26 $710.26

Estimated market price range - modelled values for guidance only, not live distributor offers.

ESP32-U4WDH Features

  • Integrated Wi-Fi and Bluetooth LE connectivity.
  • Operates in the 2.4 GHz frequency band.
  • Features 4MB Flash and 520kB SRAM.
  • Supports I²C, SPI, and UART interfaces.
  • Compact 48-QFN (5x5) surface-mount package.

ESP32-U4WDH Applications

  • Ideal for IoT device development.
  • Suitable for wireless sensor networks.
  • Enables smart home automation projects.
  • Used in embedded system designs.

ESP32-U4WDH FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating frequency of the ESP32-U4WDH?

The ESP32-U4WDH operates at 2.4 GHz.

What type of component is the ESP32-U4WDH?

The ESP32-U4WDH is a TxRx + MCU type component.

What memory is included in the ESP32-U4WDH?

The ESP32-U4WDH includes 4MB Flash, 448kB ROM, and 520kB SRAM.

What serial interfaces does the ESP32-U4WDH support?

The ESP32-U4WDH supports I²C, I²S, SPI, and UART serial interfaces.

What is the package type for the ESP32-U4WDH?

The ESP32-U4WDH is supplied in a 48-QFN package.

What is the RoHS status of the ESP32-U4WDH?

The ESP32-U4WDH is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for the ESP32-U4WDH?

The Moisture Sensitivity Level (MSL) for the ESP32-U4WDH is 1 Unlimited.
