| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
800 pcs
|
800 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Antenna Type | |
| Current | |
| Data Rate | |
| Frequency | |
| Memory Size | |
| Mounting Type | |
| Operating Temperature | |
| Power | |
| Protocol | |
| RF Family | |
| Sensitivity | |
| Serial Interfaces | |
| Tape & Reel | |
| Utilized IC | |
| Voltage |
The ESP32-S2FH4 from Espressif Systems is a highly integrated WiFi transceiver module designed for Internet of Things (IoT) applications. It features an Xtensa single-core 32-bit LX7 microprocessor and supports IEEE 802.11b/g/n protocols at a 2.4GHz frequency.
This module comes with 4MB of flash memory and offers a data rate of up to 150Mbps. It operates within a voltage range of 2.8V to 3.6V and has an output power of 19.5dBm, with a sensitivity of -97dBm. The operating temperature range is -40°C to 125°C (TJ).
Designed for surface mounting, the ESP32-S2FH4 utilizes a 56-VFQFN exposed pad package. It includes a variety of serial interfaces such as ADC, GPIO, I²C, I²S, SPI, PWM, UART, and USB, providing flexibility for integration into various designs. The module does not include an external antenna.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating voltage is 2.8V to 3.6V.
It uses a 56-VFQFN exposed pad package.
The operating temperature range is -40°C to 125°C (TJ).
