ES24P4N3A The ETEK ES24P4N3A is a TVS diode designed for power line protection. It features 7000W peak pulse power and a 24V reverse standoff voltage.
Mfr Part #:

ES24P4N3A

Available from 1 distributors
Mfr Name: ETEK
ETEK
The ETEK ES24P4N3A is a TVS diode designed for power line protection. It features 7000W peak pulse power and a 24V reverse standoff voltage.
✓ Total Stock: 900 pcs
$ Price Range: $0.99

ES24P4N3A Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Rayichip ✓
Non-Authorised Inventory information
900 pcs
On Request
900 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

ES24P4N3A Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
ESD Protection
Forward Voltage
Halogen Free
Junction Capacitance
Mounting Type
Operating Temperature
Storage Temperature
View Similar Products (0)

ES24P4N3A Description

Short technical summary and product information.

The ETEK ES24P4N3A is a solid-state silicon technology TVS diode designed for transient voltage suppression. It offers a peak pulse power of 7000 Watts at an 8/20μs waveform and a peak pulse current of 200A.



This device features a reverse stand-off voltage of 24V and a breakdown voltage of 25V at 1mA. The clamping voltage is rated at a maximum of 35V when subjected to 200A peak pulse current. It also provides excellent ESD protection, meeting IEC 61000-4-2 standards with ±30kV for both air and contact discharge.



Additional protection capabilities include IEC 61000-4-4 EFT at 40A (5/50ns) and IEC 61000-4-5 Lightning at 200A (8/20μs). The ES24P4N3A operates within a temperature range of -55°C to +125°C and comes in a low-profile DFN2020-3L package suitable for surface mounting.



Applications include protection for I/O interfaces, power lines, automotive and telecommunication systems, computer and consumer electronics, and industrial electronics. The device is RoHS compliant and meets MSL1 requirements.

ES24P4N3A Quick Information

Product Type: TVS Diode
Canonical Name: ES24P4N3A TVS Diode
Subcategory: Transient Voltage Suppression

ES24P4N3A Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

ES24P4N3A Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

ES24P4N3A Features

  • 7000 Watts peak pulse power capability.
  • 200A peak pulse current handling.
  • 24V reverse stand-off voltage.
  • ±30kV ESD protection (air and contact).
  • Low profile DFN2020-3L package.

ES24P4N3A Applications

  • Protects power lines and I/O interfaces.
  • Suitable for automotive applications.
  • Used in telecommunication systems.
  • Ideal for consumer electronics.
  • Applicable in industrial environments.

ES24P4N3A FAQs

6 frequently asked questions generated from this part’s specifications.
What is the peak pulse power of the ES24P4N3A TVS diode?

The ES24P4N3A TVS diode has a peak pulse power of 7000 Watts for an 8/20μs waveform.

What is the reverse stand-off voltage for the ES24P4N3A?

The reverse stand-off voltage for the ES24P4N3A is 24V.

What is the maximum clamping voltage of the ES24P4N3A at 200A?

The maximum clamping voltage for the ES24P4N3A at 200A (8/20μs) is 35V.

What are the operating temperature limits for the ES24P4N3A?

The operating temperature range for the ES24P4N3A is -55°C to +125°C.

What ESD protection does the ES24P4N3A offer?

The ES24P4N3A offers ±30kV ESD protection for both air and contact discharge, meeting IEC 61000-4-2 standards.

What package type is the ES24P4N3A supplied in?

The ES24P4N3A is supplied in a DFN2020-3L package.
