ES1D The ES1D is a superfast recovery rectifier diode from SLKOR. It features a 200V reverse voltage and 1A forward current.
Mfr Part #:

ES1D

Available from 1 distributors
Mfr Name: Slkor
Slkor
The ES1D is a superfast recovery rectifier diode from SLKOR. It features a 200V reverse voltage and 1A forward current.
✓ Total Stock: 50 pcs
$ Price Range: $0.40

ES1D Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
PROSOFT ELECTRONICS ✓
Non-Authorised Inventory information
50 pcs
On Request
50 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

ES1D Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Conflict Minerals
Forward Voltage
Halogen Free
Junction Capacitance
Mounting Type
Reverse Recovery Time
SVHC Present
Storage Temperature
Tape & Reel
View Similar Products (0)

ES1D Description

Short technical summary and product information.

The SLKOR ES1D is a superfast recovery rectifier diode designed for high-frequency rectification applications. It offers a repetitive peak reverse voltage of 200V and a maximum average forward rectified current of 1A at 100°C.



Key electrical characteristics include a fast reverse recovery time of 15ns, a low forward voltage of 0.92V at 1A, and a leakage current of 5µA at 200V. The diode operates within a junction temperature range of -50°C to 150°C.



Packaged in a compact DO-214AC/SMA surface-mount case, the ES1D is suitable for industrial applications. Its construction meets UL 94-V0 flammability standards.

ES1D Quick Information

Product Type: Diode
Canonical Name: ES1D Superfast Recovery Rectifier Diode
Subcategory: Superfast Recovery Rectifier

ES1D Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: No

ES1D Estimated Pricing

Qty Low High
1+ $0.40 $0.40

Estimated market price range - modelled values for guidance only, not live distributor offers.

ES1D Features

  • Superfast recovery time of 15ns.
  • 200V repetitive peak reverse voltage.
  • 1A maximum average forward current.
  • Low 0.92V forward voltage.
  • SMA surface-mount package.

ES1D Applications

  • Ideal for high-frequency rectification.
  • Suitable for industrial applications.
  • Used in power supply circuits.
  • General purpose rectification needs.

ES1D FAQs

6 frequently asked questions generated from this part’s specifications.
What is the reverse recovery time of the ES1D diode?

The reverse recovery time of the ES1D diode is 15 ns.

What is the maximum repetitive peak reverse voltage for the ES1D?

The maximum repetitive peak reverse voltage for the ES1D is 200 V.

What is the maximum average forward rectified current of the ES1D at 100°C?

The maximum average forward rectified current of the ES1D at 100°C is 1.00 A.

What is the forward voltage of the ES1D at 1A and 25°C?

The forward voltage of the ES1D at 1A and 25°C is 0.92 V.

What is the package type for the ES1D diode?

The ES1D diode is supplied in a DO-214AC/SMA package.

What is the operating junction temperature range for the ES1D?

The operating junction temperature range for the ES1D is -50°C to 150°C.
