| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
149 pcs
|
149 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Features | |
| Height Above Board | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Packaging Type | |
| Pitch | |
| Termination Style |
The Samtec ERM8-020-01-S-D-RA-K-TR is a 40 position, 2 row header with center strip contacts designed for board-to-board mezzanine applications. It features a 0.80mm pitch and right angle surface mount termination, making it suitable for high-density interconnects where space is constrained.
The connector has gold contact finish with 30.0µin (0.76µm) thickness for reliable signal integrity. It includes board guide, mounting flange, and pick and place features for automated assembly. The part is packaged in Tape & Reel for volume production.
With a height above board of 0.246" (6.25mm), this connector is ideal for parallel board stacking applications. The right angle orientation allows for edge-mount configurations.
40 positions arranged in 2 rows.
0.80mm (0.031").
Surface mount, right angle.
Gold with 30.0µin (0.76µm) thickness.
Tape & Reel.
