| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
9,736 pcs
|
9736 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
6,540 pcs
|
6540 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
4,230 pcs
|
4230 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Composition | |
| Features | |
| Height | |
| Length | |
| Number of Terminations | |
| Operating Temperature | |
| Power (Watts) | |
| Ratings | |
| Resistance | |
| Storage Temperature | |
| Supplier Device Package | |
| Tape & Reel | |
| Temperature Coefficient | |
| Tolerance | |
| Voltage Rating | |
| Width |
This Panasonic ERJ-12SF1540U is a surface mount thick film resistor designed for various electronic applications. It offers a resistance value of 154 Ohms with a tight tolerance of 1%, ensuring precise circuit performance.
The resistor has a power rating of 0.75W (3/4W) and a temperature coefficient of ±100ppm/°C, making it suitable for applications with moderate power requirements and stable operation across a temperature range of -55°C to +155°C.
Packaged in a 2010 (5025 Metric) case size, this component is designed for surface mounting. Its dimensions are 5.00mm in length and 2.50mm in width, with a height of 0.70mm. The component is also AEC-Q200 qualified, indicating its suitability for automotive applications.
Available in Cut Tape (CT) or Reel packaging, the ERJ-12SF1540U is a reliable choice for designers needing a high-quality thick film resistor.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 154 Ohms.
The tolerance is ±1%.
The power rating is 0.75W, or 3/4W.
The operating temperature range is -55°C to +155°C.
The package size is 2010 (5025 Metric).
Yes, this resistor features Automotive AEC-Q200 qualification.
The voltage rating is 200V.
