The Mean Well USA EPS-15-12 is a 15W, single-output AC-DC converter designed for commercial ITE applications. It delivers a regulated 12V output at up to 1.25A with an efficiency of 82%.
The converter accepts a universal AC input and provides 3kV input-to-output isolation. The output is adjustable, allowing fine-tuning within a limited range to accommodate system requirements.
Mechanically, the EPS-15-12 features an open-frame chassis-mount design with dimensions of 63.5 mm x 45.7 mm x 24.0 mm. It operates over a wide temperature range of -30°C to 70°C with derating, making it suitable for environments requiring robust thermal performance.
The power supply carries safety approvals from CB, CE, cURus, and TUV agencies and is listed as RoHS3 compliant (unverified). It is intended for use in information technology equipment and similar commercial electronics.
12 V DC.
1.25 A.
15 W.
-30°C to 70°C with derating.
Open frame, chassis mount.
It is reported as RoHS3 compliant, but this is unverified.
82% typical.
