| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8 pcs
|
8 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Isolation Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Power (Convection) | |
| Power (Forced Air) | |
| Power (Watts) | |
| Storage Temperature | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
The EPP-150-15 from Mean Well USA is a single-output AC/DC converter designed for commercial ITE applications. It delivers a 15V output at 6.7A with a convection power rating of 101W, which can be increased to 150W with forced air cooling. The unit achieves 92% efficiency and offers 3kV input-to-output isolation.
The converter features an open frame chassis mount package with dimensions of 101.6mm x 50.8mm x 29.0mm (4.00" x 2.00" x 1.14"). It includes adjustable output voltage, power factor correction (PFC), and accepts a universal input range. The operating temperature range is -30°C to 70°C with derating.
Approvals include CB, CE, cURus, and TUV, and the part is listed as RoHS3 compliant and REACH unaffected. The part is cross-referenced as Digi-Key part number 1866-1641-ND.
The output voltage is 15 V and the output current is 6.7 A.
The convection power rating is 101W. With forced air cooling, the rating increases to 150W.
The operating temperature range is -30°C to 70°C with derating.
The efficiency is 92%.
The approval agencies are CB, CE, cURus, and TUV.
It is an open frame converter with chassis mount. Dimensions are 101.6mm x 50.8mm x 29.0mm (4.00" x 2.00" x 1.14").
