EPM7064STC100-7N The Intel EPM7064STC100-7N is a CPLD featuring 64 macrocells and a 7.5 ns propagation delay. It operates at 5.0V and is available in a surface mount package.
Mfr Part #:

EPM7064STC100-7N

Available from 2 distributors
Mfr Name: Intel
Intel
The Intel EPM7064STC100-7N is a CPLD featuring 64 macrocells and a 7.5 ns propagation delay. It operates at 5.0V and is available in a surface mount package.
✓ Total Stock: 350 pcs

EPM7064STC100-7N Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Flip Electronics ✓
Non-Authorised Inventory information
347 pcs
On Request
347 pcs On Request 1 On Request On Request On Request On Request On Request
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
3 pcs
On Request
3 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

EPM7064STC100-7N Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Delay Time tpd(1) Max
Industrial Grade
Medical Grade
Military Grade
Mounting Type
Number of Gates
Number of I
Number of Logic Elements
Number of Macrocells
Operating Temperature
Programmable Type
Supplier Device Package
Tape & Reel
Voltage Supply
View Similar Products (0)

EPM7064STC100-7N Description

Short technical summary and product information.

The Intel EPM7064STC100-7N is a high-performance, EEPROM-based programmable logic device belonging to the MAX 7000 family. It offers 64 macrocells and 1250 usable gates, with a pin-to-pin logic delay of 7.5 ns. This device supports in-system programmability and operates at a supply voltage of 4.75V to 5.25V.



Designed for flexibility, the EPM7064STC100-7N features 68 I/O pins and a maximum counter frequency of 90.9 MHz. It includes programmable macrocell flipflops, a programmable power-saving mode, and configurable expander product-term distribution. The device is suitable for applications requiring PCI compliance.



This CPLD comes in a 100-TQFP (14x14) package and is designed for surface mounting. The operating temperature range is 0°C to 70°C (TA). It also supports features like JTAG boundary-scan circuitry and MultiVolt I/O interface operation.

EPM7064STC100-7N Quick Information

Product Type: CPLD
Series: MAX 7000
Canonical Name: Intel EPM7064STC100-7N CPLD
Subcategory: Complex Programmable Logic Devices

EPM7064STC100-7N Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

EPM7064STC100-7N Features

  • 64 macrocells and 1250 usable gates.
  • 7.5 ns pin-to-pin logic delay.
  • 5.0V supply voltage operation.
  • Surface mount 100-TQFP package.
  • In-system programmable logic device.

EPM7064STC100-7N Applications

  • Ideal for logic density applications.
  • Suitable for PCI compliant designs.
  • Supports in-system programming needs.
  • Flexible I/O for various interfaces.

EPM7064STC100-7N FAQs

6 frequently asked questions generated from this part’s specifications.
What is the number of macrocells in the EPM7064STC100-7N?

The EPM7064STC100-7N has 64 macrocells.

What is the propagation delay of the EPM7064STC100-7N?

The maximum propagation delay (tpd) for the EPM7064STC100-7N is 7.5 ns.

What is the operating voltage for the EPM7064STC100-7N?

The EPM7064STC100-7N operates at a supply voltage of 5.0V.

What is the operating temperature range for this CPLD?

The operating temperature range for the EPM7064STC100-7N is 0°C to 70°C (TA).

What package type is the EPM7064STC100-7N supplied in?

The EPM7064STC100-7N is supplied in a 100-TQFP (14x14) package.

Does the EPM7064STC100-7N support in-system programmability?

Yes, the EPM7064STC100-7N supports 5.0-V in-system programmability (ISP).
