EPM7032AETC44-10 The Intel EPM7032AETC44-10 is a Complex Programmable Logic Device (CPLD) with 32 macrocells and a 10ns propagation delay. It operates at 3V to 3.6V and is available in a 44-TQFP surface mount package.
Mfr Part #:

EPM7032AETC44-10

Available from 1 distributors
Mfr Name: Intel
Intel
The Intel EPM7032AETC44-10 is a Complex Programmable Logic Device (CPLD) with 32 macrocells and a 10ns propagation delay. It operates at 3V to 3.6V and is available in a 44-TQFP surface mount package.
✓ Total Stock: 6,000 pcs

EPM7032AETC44-10 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
6,000 pcs
On Request
6000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

EPM7032AETC44-10 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Delay Time tpd(1) Max
Mounting Type
Number of Gates
Number of I
Number of I/O
Number of Logic Elements
Number of Macrocells
Operating Temperature
Programmable Type
Supplier Device Package
Tape & Reel
Voltage Supply
View Similar Products (0)

EPM7032AETC44-10 Description

Short technical summary and product information.

The Intel EPM7032AETC44-10 is a high-performance, 3.3-V EEPROM-based programmable logic device (PLD) from the MAX 7000A family. It features 32 macrocells, 36 I/O pins, and 600 gates, offering a propagation delay of 10 ns.



This CPLD supports in-system programmability (ISP) and operates within a voltage supply range of 3V to 3.6V. The device is designed for surface mounting and comes in a 44-TQFP package.



Key electrical characteristics include a maximum propagation delay of 10 ns and an operating temperature range of 0°C to 70°C (TA). The MAX 7000A architecture provides predictable performance and flexibility for various embedded applications.

EPM7032AETC44-10 Quick Information

Product Type: CPLD
Series: MAX 7000A
Canonical Name: Intel EPM7032AETC44-10 Complex Programmable Logic Device
Subcategory: Complex Programmable Logic Devices

EPM7032AETC44-10 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

EPM7032AETC44-10 Features

  • 32 macrocells and 600 gates.
  • 10ns maximum propagation delay.
  • 3.3V to 3.6V operating voltage.
  • 44-TQFP surface mount package.
  • 0°C to 70°C operating temperature.

EPM7032AETC44-10 Applications

  • Used in embedded control systems
  • Suitable for interface control circuits
  • Ideal for logic expansion modules
  • Applicable in high-speed digital applications

EPM7032AETC44-10 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the operating voltage for the EPM7032AETC44-10?

The operating voltage supply for the EPM7032AETC44-10 is 3V to 3.6V.

What package type is the EPM7032AETC44-10 supplied in?

The EPM7032AETC44-10 is supplied in a 44-TQFP (10x10) package.

What is the operating temperature range for this CPLD?

The operating temperature range for the EPM7032AETC44-10 is 0°C to 70°C (TA).

What is the RoHS status of the EPM7032AETC44-10?

The RoHS status is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for the EPM7032AETC44-10?

The Moisture Sensitivity Level (MSL) is 1 Unlimited.
