| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Input Frequency | |
| Medical Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Overload Protection | |
| Package / Case | |
| Power (Watts) | |
| Type | |
| Voltage |
The Astrodyne TDI EPM15-150-BE-0F0 is a 15 Watt AC/DC converter designed for medical applications. It features a universal input voltage range of 80 to 275 VAC, operating at 50/60 Hz. The converter provides a regulated 15VDC output with a maximum current of 1A.
Key electrical specifications include an efficiency of typically 70%, over-voltage protection, overload protection with auto-recovery, and short circuit protection. The unit offers 4000 VAC isolation between input and output and has an isolation resistance of 50 MW. It operates within a temperature range of -20°C to 70°C with derating.
Mechanically, the converter has dimensions of 65.0mm x 45.0mm x 20.0mm. It is designed for Through Hole mounting and comes in a 5-DIP Module, 4 Leads package. Safety approvals include CB, CE, cTUVus, and TUV, indicating compliance with relevant industry standards for medical equipment.
This power supply is suitable for various medical applications requiring reliable and efficient power conversion. Its robust design and safety certifications make it a dependable choice for demanding environments.
80-275 VAC
15 VDC at 1A maximum
-20°C to 70°C with derating
5-DIP Module, 4 Leads (Through Hole)
4000 VAC input to output
IEC 60601-1 3rd Ed Amend 1, IEC 62368-1, IEC 60950-1, CSA C22.2, CB Scheme
>70% typical
