| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
760 pcs
|
760 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Drain to Source Voltage (Vdss) | |
| Drive Voltage (Max Rds On, Min Rds On) | |
| FET Type | |
| Input Capacitance (Ciss) (Max) @ Vds | |
| Mounting Type | |
| Operating Temperature | |
| Rds On (Max) @ Id, Vgs | |
| Supplier Device Package | |
| Technology | |
| Vgs (Max) | |
| Vgs(th) (Max) @ Id |
The EPC2025 is a 300V N-Channel Gallium Nitride FET (GaNFET) from EPC. It is designed for high-efficiency power conversion applications requiring fast switching and low on-resistance. The device is rated for 4A continuous drain current (at 25°C ambient) and achieves a maximum on-resistance of 150mOhm at 3A drain current and 5V gate drive.
Key electrical characteristics include a gate threshold voltage of 2.5V maximum at 1mA drain current, and an input capacitance of 194pF at 240V drain-source voltage. The device operates over a junction temperature range of -40°C to 150°C. The gate-source voltage is limited to +6V and -4V.
Packaged as a bare die, the EPC2025 is intended for surface mount assembly using standard die attach and wire bonding processes. The die form factor enables minimal parasitic inductance and compact power stage designs, making it suitable for high-frequency DC-DC converters, inverters, and wireless power systems.
| Qty | Low | High |
|---|---|---|
| 3,000+ | $2.36 | $2.36 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The drain-source voltage rating is 300V.
The maximum continuous drain current is 4A at ambient temperature.
The maximum on-resistance is 150mOhm at 3A drain current and 5V gate drive.
The operating junction temperature range is -40°C to 150°C.
The package is a bare die, intended for surface mount assembly.
The maximum gate threshold voltage is 2.5V at 1mA drain current.
The RoHS status is listed as RoHS3 compliant but this is unverified; treat as low confidence.
