The XP Power EML30US15-S is an AC-DC converter from the EML30 series, designed for medical applications. This model provides a single 15VDC output with a nominal power rating of 30W and a nominal output current of 2A.
Key electrical specifications include an input voltage range of 85-264 VAC or 120-370 VDC, with an efficiency of up to 88% (typical 87%). It operates within a temperature range of -20°C to 70°C with derating.
The unit is designed for chassis mounting and features a compact size with dimensions of 96.0mm x 40.0mm x 28.5mm. It also offers a peak load capability of 130% for 30 seconds and meets Class II isolation standards.
This power supply is suitable for various healthcare and medical diagnostic applications, benefiting from approvals to worldwide medical safety standards and compliance with Class B emissions.
Output voltage is 15VDC nominal and output current is 2A, delivering 30W total power.
The input voltage range is 85-264 VAC (47-63 Hz) or 120-370 VDC.
Operating temperature range is -20°C to +70°C with derating. Full output up to +50°C, linearly derated to 50% load at +70°C.
Input-to-output isolation voltage is 4 kV.
Chassis mount.
No minimum load is required; it can operate from 0A up to full load.
