ELL-6UH151M The Panasonic ELL-6UH151M is a wirewound fixed inductor offering 150µH inductance and a 500mA current rating. It features a surface mount, shielded package.
Mfr Part #:

ELL-6UH151M

Available from 1 distributors
Mfr Name: Panasonic Electronic Components
Panasonic Electronic Components
The Panasonic ELL-6UH151M is a wirewound fixed inductor offering 150µH inductance and a 500mA current rating. It features a surface mount, shielded package.
✓ Total Stock: 550 pcs

ELL-6UH151M Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
550 pcs
On Request
550 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

ELL-6UH151M Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current Rating (Amps)
DC Resistance (DCR)
Height
Inductance
Length
Mounting Type
Shielding
Tolerance
Type
Width
View Similar Products (0)

ELL-6UH151M Description

Short technical summary and product information.

The Panasonic ELL-6UH151M is a wirewound fixed inductor designed for various electronic applications. It provides an inductance value of 150µH with a tolerance of ±20% and can handle a current rating of 500mA.



This inductor features a low DC resistance of 680mOhm. Its construction is shielded, making it suitable for applications where electromagnetic interference needs to be minimized. The component is designed for surface mounting, with dimensions of 6.40mm in length and 6.00mm in width, and a height of 5.00mm.



Key electrical characteristics include its wirewound type and a nominal inductance of 150µH. The component is specified for a current rating of 500mA and has a DC resistance of 680mOhm. Its physical dimensions are optimized for compact PCB layouts, with a surface mount package.



The ELL-6UH151M is a reliable component for power supply circuits, filtering applications, and other signal processing tasks requiring stable inductance. Its shielded design helps maintain signal integrity in noise-sensitive environments.

ELL-6UH151M Quick Information

Product Type: Fixed Inductor
Canonical Name: Panasonic ELL-6UH151M Wirewound Fixed Inductor
Subcategory: Wirewound

ELL-6UH151M Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

ELL-6UH151M Features

  • 150µH inductance with ±20% tolerance.
  • 500mA current rating for power applications.
  • Low 680mOhm DC resistance.
  • Shielded construction for EMI reduction.
  • Compact surface mount package.

ELL-6UH151M Applications

  • Suitable for power supply filtering.
  • Used in signal processing circuits.
  • Ideal for noise-sensitive applications.
  • Compact design for PCB integration.

ELL-6UH151M FAQs

7 frequently asked questions generated from this part’s specifications.
What is the inductance of the ELL-6UH151M?

The inductance of the ELL-6UH151M is 150µH.

What is the current rating for the ELL-6UH151M?

The current rating for the ELL-6UH151M is 500mA.

What is the DC resistance (DCR) of this inductor?

The DC resistance (DCR) of the ELL-6UH151M is 680mOhm.

What type of inductor is the ELL-6UH151M?

The ELL-6UH151M is a wirewound fixed inductor.

How is the ELL-6UH151M mounted?

The ELL-6UH151M is designed for surface mounting.

Is the ELL-6UH151M shielded?

Yes, the ELL-6UH151M is a shielded inductor.

What are the dimensions of the ELL-6UH151M?

The dimensions of the ELL-6UH151M are 6.40mm x 6.00mm with a height of 5.00mm.
