| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,000 pcs
|
2000 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Height | |
| Inductance | |
| Length | |
| Mounting Type | |
| Shielding | |
| Tape & Reel | |
| Test Frequency | |
| Tolerance | |
| Type | |
| Width |
The Panasonic ELL-4LG1R0NA is a fixed inductor from the ELL4LG-A series, featuring a shielded wirewound construction. It offers an inductance of 1 µH (measured at 100 kHz) with a tolerance of ±30%. The DC resistance is a maximum of 43 mOhm at 20°C. The inductor is rated for a maximum saturation current of 1.9 A and a rated rise current of 2.2 A. It is designed for surface mount mounting in a nonstandard package with dimensions 3.80 mm x 3.80 mm x 1.80 mm. The component is RoHS compliant and suitable for applications such as DC/DC converters in portable electronics.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.46 | $0.46 |
| 10+ | $0.38 | $0.38 |
| 100+ | $0.31 | $0.31 |
| 1,000+ | $0.25 | $0.25 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance is 1 µH, measured at 100 kHz, with a tolerance of ±30%.
The DC resistance (DCR) is a maximum of 43 mOhm at 20°C.
The maximum saturation current is 1.9 A.
The rated rise current is a maximum of 2.2 A.
The package is nonstandard surface mount with dimensions 3.80 mm x 3.80 mm x 1.80 mm. Mounting type is surface mount.
Yes, it has a magnetic shielded structure (shielded wirewound type).
Yes, it is RoHS3 compliant per the datasheet.
