| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
7 pcs
|
7 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Height | |
| Length | |
| Mounting Style | |
| Number of Drivers | |
| Output Current | |
| Power Dissipation | |
| Width |
The Renesas EL7212CSZ is a dual-channel gate driver designed for efficient power management applications. This IC provides a robust solution with a 2A output current capability, suitable for driving MOSFETs and other power switching devices.
Key electrical specifications include an operating supply voltage range from 4.5V to 15V, with a typical operating supply current of 2.5mA. The device exhibits a fast rise time of 10 ns and a fall time of 13 ns, ensuring rapid switching performance.
Packaged in a compact SOIC-8 surface-mount case, the EL7212CSZ is designed for ease of integration into printed circuit boards. It operates reliably within a temperature range of -40°C to +85°C, making it suitable for various environmental conditions. The power dissipation is rated at 570mW.
This gate driver is manufactured by Renesas and is supplied on a reel, with a factory pack quantity of 1000 units. Its dimensions are 4.9mm in length, 3.9mm in width, and 1.45mm in height.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The EL7212CSZ operates within a supply voltage range of 4.5 V to 15 V.
The EL7212CSZ is supplied in a SOIC-8 surface mount package.
The EL7212CSZ can operate from -40 °C to +85 °C.
The EL7212CSZ has 2 drivers.
The maximum output current for the EL7212CSZ is 2 A.
The EL7212CSZ has a rise time of 10 ns and a fall time of 13 ns.
The power dissipation for the EL7212CSZ is 570 mW.
