| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Dimensions | |
| Efficiency | |
| Features | |
| Input Voltage | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage |
The Astrodyne TDI EFM-0308 is a 30W AC DC converter designed for board mount applications. It features a dual output configuration with voltages of 5V and 12V, and a maximum output current of 3A and 1.25A respectively. The converter operates with a universal input voltage range of 90 to 264 VAC and offers a nominal efficiency of 74%.
This open frame converter is designed for through-hole mounting and comes in a 6-DIP Module, 5 Leads package. It has dimensions of 3.94" L x 2.36" W x 0.93" H (100.0mm x 60.0mm x 23.5mm). The EFM-0308 series is built to meet standard number 60950-1 and carries approvals from CB, CE, cURus, and UL agencies.
Key electrical specifications include line regulation of ±1% and load regulation of ±2% and ±4%. The operating temperature range is from -20°C to 40°C. Its features include universal input capability, making it versatile for various power supply needs in ITE (Commercial) equipment.
The EFM-0308 has dual outputs of 5V and 12V.
The maximum output currents are 3A for the 5V output and 1.25A for the 12V output.
The EFM-0308 accepts a universal input voltage range of 90 to 264 VAC.
The power rating for this converter is 30W.
The operating temperature range is -20°C to 40°C.
This converter is designed for through-hole mounting.
The dimensions are 3.94" L x 2.36" W x 0.93" H (100.0mm x 60.0mm x 23.5mm).
