| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
34,800 pcs
|
34800 pcs | On Request | 1 | On Request | On Request | 1813+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Current Consumption | |
| Forward Current | |
| Forward Voltage | |
| Hysteresis | |
| Mounting Type | |
| Operating Temperature | |
| Output Configuration | |
| Output Current | |
| Output Voltage | |
| Response Frequency | |
| Reverse Current | |
| Reverse Voltage | |
| Sensing Distance | |
| Sensing Method | |
| Storage Temperature | |
| Tape & Reel | |
| Voltage |
The Omron EE-SX4134 is an ultra-compact, PCB surface mounting type transmissive photomicrosensor. It features a Photo IC output and operates within a supply voltage range of 2.2V to 7V.
This sensor has a sensing distance of 2mm and an NPN open collector output configuration. Key electrical characteristics include a typical current consumption of 2.8 mA and a response frequency of 3 kHz minimum. The device also offers a typical hysteresis of 21% and response delay times of 7 μs (tPHL) and 18 μs (tPLH).
Designed for through-beam sensing, the EE-SX4134 is housed in a 6-SMD package, making it suitable for applications requiring space-efficient optical sensing solutions. Its operating temperature range is -25°C to 85°C.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.50 | $0.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The EE-SX4134 operates within a supply voltage range of 2.2V to 7V.
The sensing distance for the EE-SX4134 is 0.079 inches (2mm).
The EE-SX4134 features an NPN open collector output configuration.
The operating temperature range for the EE-SX4134 is -25°C to 85°C.
The EE-SX4134 is available in a 6-SMD package.
