| Specifications |
The EDATEC ED-PSU1201-US is an AC/DC adapter with a 12VDC, 1.0A output, providing a maximum power of 12.0W. It operates with a wide input voltage range of 100-240VAC at 50/60Hz, making it suitable for various regions.
This adapter is equipped with crucial protection mechanisms, including over-voltage, short-circuit, and overcurrent protection, ensuring safe and reliable operation. It features a 1.5-meter power cable with a 24 AWG gauge and a standard 5.5*2.5*9.5mm DC plug.
The operating temperature range for this unit is 0-40°C. It meets RoHS3 compliance standards and has an MSL rating of 1, indicating unlimited shelf life under proper storage conditions. The adapter is designed for desktop or wall-mounted applications.
Key electrical specifications include line regulation of less than 0.5%, load regulation of less than 1.0%, and peak load regulation of less than 2.0%. The ripple and noise are kept below 120mVp-p. Average efficiency is a minimum of 75%.
100-240 VAC.
12.0 VDC at 1.0 A.
12.0 W.
0-40°C.
5.5 mm outer diameter by 2.5 mm inner diameter, 9.5 mm barrel length.
1.5 m (24 AWG).
Over-voltage, short-circuit, and overcurrent protection.
