| Category | |
| Manufacturer Name | |
| Accessory Type | |
| Input Frequency | |
| Lead Style | |
| Output Power | |
| Output Voltage | |
| Power Consumption | |
| Region Utilized | |
| Specifications |
The EDATEC ED-PSU1201-AU is an AC/DC adapter with a 12VDC, 1.0A output, providing a maximum of 12.0W of power. It is designed for use with a 100-240VAC, 50/60Hz input, making it suitable for various regions, including Australia.
This adapter features built-in over-voltage, short-circuit, and overcurrent protection to ensure safe and reliable operation. It comes with a 1.5-meter power cable and a standard 5.5*2.5*9.5mm DC plug. The operating temperature range is from 0°C to 40°C.
Key electrical specifications include a rated input current of 0.3A max, no-load power consumption of 0.5W max, line regulation of less than 0.1%, and load regulation of less than 0.2%. The ripple and noise are kept below 150mVp-p. It also features a turn-on delay time of 1000ms max and a rise time of 20ms.
The ED-PSU1201-AU adapter has a nominal DC output voltage of 12V and a rating load current of 1A.
The ED-PSU1201-AU adapter accepts a rated input voltage range of 100-240VAC.
The ED-PSU1201-AU adapter has a maximum output power rating of 12W.
The ED-PSU1201-AU adapter includes over-voltage, short-circuit, and overcurrent protection.
The ED-PSU1201-AU adapter operates within a temperature range of 0°C to 40°C.
