The ECS-2520S33-500-FN-TR is a 50 MHz HCMOS crystal oscillator from ECS Inc. in the miniature 2.5 x 2.0 x 0.9 mm 4-SMD, No Lead ceramic package. It operates from a 3.3 V supply with a typical current consumption of 7 mA and a standby current of only 10 µA. The oscillator provides a frequency stability of ±10 ppm over the full -40 to +85°C temperature range, making it suitable for applications requiring precise timing.
Key electrical characteristics include a 45/55% duty cycle, 5 ns rise/fall time, and a startup time of 10 ms. The output is HCMOS with a 15 pF load, and the device features a tri-state function (active low) for output enable/disable. Phase noise at 10 kHz offset is -145 dBc/Hz.
The oscillator is RoHS3 compliant with MSL 1 and lead finish Au. It is supplied in tape and reel packaging with 1000 units per reel. The compact footprint and low profile are ideal for space-constrained designs in wireless and IoT applications.
The supply voltage is 3.3 V with ±10% tolerance.
It comes in a 4-SMD, No Lead ceramic package measuring 2.5 mm x 2.0 mm x 0.9 mm.
The operating temperature range is -40°C to +85°C.
Yes, it is RoHS3 compliant.
The frequency stability is ±10 ppm over the operating temperature range.
The output is HCMOS with a 15 pF load.
Yes, it has a tri-state function (active low) on pin 1 for output enable/disable.
