| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8,000 pcs
|
8000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Capacitance | |
| Dimensions | |
| Dissipation Factor | |
| Lead Spacing | |
| Mounting Type | |
| Operating Temperature | |
| Voltage | |
| Weight |
This Hitano ECR102M63B is an aluminum electrolytic capacitor designed for various electronic applications. It offers a nominal capacitance of 1000 microfarads (uF) and a maximum working voltage of 63 volts (V).
The capacitor features a dissipation factor of 10% and a maximum leakage current of 630 microamperes (uA). Its operating temperature range is from -40°C to 85°C, with a rated lifetime of 2000 hours at 85°C. The capacitance tolerance is ±20%.
With dimensions of 16 x 26 mm, this radial capacitor has a lead spacing of 7.5 mm. It has a ripple current rating of 1550 mA and weighs approximately 9 grams. The standard package quantity is 7 units.
This component is suitable for applications requiring stable capacitance and voltage handling within its specified operating parameters. Its through-hole mounting type makes it suitable for traditional PCB assembly.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.10 | $0.10 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal capacitance is 1000 uF.
The rated voltage is 63 V.
The capacitance tolerance is ±20%.
The operating temperature range is -40°C to 85°C.
The lifetime is 2000 hours at 85°C.
The package is radial through-hole with dimensions 16 x 26 mm and lead spacing of 7.5 mm.
The ripple current rating is 1550 mA.
