The XP Power ECP150PS48 is a 100W AC/DC converter designed for ITE (Commercial) and Medical applications. It features a compact 2" x 4" footprint and a low profile of 1.26 inches, making it suitable for space-constrained designs.
This converter operates with a universal input voltage range of 90-264 VAC and achieves up to 92% efficiency. Key electrical specifications include a 48V output voltage, 3.10A output current, and a typical ripple and noise of 480mV pk-pk. It also includes a built-in 12V/0.5A fan supply.
The ECP150PS48 is safety approved to operate in a 70°C ambient temperature and meets conducted emissions standards. It is designed with low leakage currents required for medical applications and features adjustable output voltage with a range of ±10%.
Mounting is via chassis mount, and the open-frame construction facilitates integration into various equipment. The unit complies with standard IEC 62368-1.
The input voltage range is 90-264 VAC at 47-63 Hz.
The output is 48 VDC at 3.1 A, providing 100 W (150 W forced air).
Typical efficiency is 92%.
The operating temperature range is -20°C to 70°C with derating.
It is an open frame package for chassis mounting.
Yes, ripple and noise is 480 mV pk-pk.
Yes, the output voltage can be adjusted by ±10% via a potentiometer.
