| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Input Frequency | |
| Input Voltage | |
| Isolation | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Overload Protection | |
| Power (Watts) | |
| Standard Number | |
| Temperature Coefficient | |
| Type | |
| Voltage |
The XP Power ECL15UD03-E is a 15W AC/DC converter designed for ITE (Commercial) applications. It features a compact, enclosed package with Through Hole mounting, making it suitable for board-level integration.
This converter operates with a wide input voltage range of 85-264 VAC and provides dual outputs of +5V and -12V, delivering a total of 15W. Key electrical specifications include an efficiency of 81%, a switching frequency of 70 kHz, and isolation of 3000 VAC.
Environmental and safety features include an operating temperature range of -20°C to 70°C with derating, convection cooling, and compliance with standards such as 62368-1. The unit is designed with overload and short circuit protection in a hiccup mode.
With its versatile input, dual outputs, and robust design, the ECL15UD03-E is a reliable power solution for various industrial and commercial electronic equipment.
85-264 VAC (120-370 VDC).
6-DIP Module, through-hole mounting.
-20°C to 70°C with derating.
+5V and -12V.
81%.
Overvoltage, overload, and short circuit protection.
3000 VAC input to output.
