| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Input Frequency | |
| Input Voltage | |
| Isolation | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Standard Number | |
| Temperature Coefficient | |
| Type | |
| Voltage |
The XP Power ECL05US09-T is an AC-DC converter from the ECL Series, designed for applications requiring a 9V output with a 5W power rating. It operates with a universal input voltage range of 85-264 VAC and features a low no-load input power of less than 0.3W. The converter boasts an efficiency of 78% and provides a 3000 VAC isolation between input and output.
Designed for flexibility, this model offers adjustable output voltage on output 1 with ±5% trim. It includes essential protections such as overvoltage, overload, and short circuit protection in a hiccup mode. The operating temperature range is -20°C to 70°C with derating.
With its open frame construction and chassis mount type, the ECL05US09-T is suitable for integration into various systems. Its dimensions are 87.9mm x 34.6mm x 22.4mm. The product comes with a 3-year warranty, highlighting its reliability for industrial and commercial applications.
The output voltage is 9V.
The input voltage range is 85-264 VAC (120-370 VDC).
The operating temperature range is -20°C to 70°C with derating.
Dimensions are 87.9mm x 34.6mm x 22.4mm (L x W x H).
The efficiency is 78%.
The isolation voltage is 3000 VAC input to output.
The mounting type is chassis mount.
