| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,280 pcs
|
2280 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Capacitance | |
| Dielectric Material | |
| Height | |
| Length | |
| Mounting Type | |
| Operating Temperature | |
| Package / Case | |
| Tape & Reel | |
| Termination | |
| Termination Style | |
| Tolerance | |
| Voltage - Rated | |
| Voltage Rating | |
| Width |
The ECH-U1H101GX5 is a surface-mount film capacitor manufactured by Panasonic Electronic Components. It features a capacitance of 100 pF with a tolerance of ±2% and a rated voltage of 50V DC. The dielectric material is polyphenylene sulfide (PPS) with a metallized stacked construction.
This capacitor is housed in an 0805 (2012 Metric) package with solder pad terminations. Its dimensions are 2.00mm x 1.25mm x 1.10mm. It operates over a temperature range of -55°C to 125°C, making it suitable for a wide variety of environments.
The PPS dielectric offers stable capacitance over temperature and frequency, making it ideal for timing, filtering, and coupling applications in general purpose circuits. The surface mount design enables automated assembly.
100 pF
50V DC
±2%
Polyphenylene Sulfide (PPS), metallized stacked
0805 (2012 Metric) surface mount
-55°C to 125°C
Surface mount with solder pads
