| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Current - Output 1 | |
| Current - Output 2 | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| SVHC Present | |
| Standard Number | |
| Switching Frequency | |
| Type | |
| Voltage | |
| Voltage - Input (Max) | |
| Voltage - Input (Min) | |
| Voltage - Isolation | |
| Voltage - Output 1 | |
| Voltage - Output 2 | |
| Width |
The Cincon EC4BE16 is a 10W isolated DC-DC converter module in the EC4BE series. It accepts a nominal 48V input with a 36-72V range and provides dual regulated outputs of +5V and -5V, each capable of delivering up to 1A. The module achieves up to 80% efficiency and includes continuous short circuit protection (SCP).
Designed for commercial ITE applications, the converter features 500V input-to-output isolation and a switching frequency of 200 kHz. It is housed in a compact 2.00" x 1.00" x 0.40" (50.8mm x 25.4mm x 10.2mm) six-sided shielded metal case with through-hole mounting in a 5-DIP module package.
The operating temperature range is -25°C to +71°C with derating above 71°C. The module carries CE and cURus approvals to UL60950-1 and meets EN55032 Class A conducted emissions.
Output 1 is +5V at 1A and Output 2 is -5V at 1A.
The input voltage range is 36V to 72V DC, with a nominal of 48V.
The operating temperature range is -25°C to +71°C without derating.
It is a through-hole 5-DIP module measuring 50.8mm x 25.4mm x 10.2mm.
It is approved to CE and cURus standards, specifically UL60950-1.
RoHS3 compliant status is indicated but unverified.
