The Carlo Gavazzi E82-2050 is an AC current transducer that converts a primary AC current up to 50 A into a proportional 4-20 mA DC signal. It is loop powered, eliminating the need for an external power supply. The device is designed for wall mounting in control panels and features an IP40-rated enclosure. Dimensions are 95 x 67.5 x 20 mm with a 27 mm mounting hole, and it weighs approximately 270 g. Operating temperature range is -20 to +50 °C. The transducer carries UL approval for industrial environments. It delivers a fixed 4-20 mA output suitable for direct connection to PLCs and instrumentation inputs. As part of Carlo Gavazzi's A82 line, it senses current by passing the conductor through an internal element and outputs a proportional loop current.
| Qty | Low | High |
|---|---|---|
| 1+ | $255.00 | $255.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating temperature range is -20 to +50 °C.
The maximum primary input current is 50 A.
The output is a 4-20 mA DC loop-powered signal.
It is designed for wall mounting.
The enclosure rating is IP40.
It has UL approval.
It is loop-powered.
