The Tri-Mag, LLC DZ100-14 is a 100 Watt universal input AC/DC power supply designed for ITE (Commercial) applications. It operates within a wide input voltage range of 90 to 264 VAC and provides a single 48V DC output.
This power supply features Power Factor Correction (PFC) with a power factor greater than 0.95. It offers high efficiency, typically between 85% and 90%, and includes essential protections such as Overvoltage (Latch Off), Overload (Auto Recovery), and Short Circuit (Auto Recovery).
The DZ100-14 has a compact open frame design suitable for chassis mounting. Its dimensions are 127.0mm x 76.2mm x 30.0mm (5.00" x 3.00" x 1.18"). The operating temperature range is 0°C to 70°C, with cooling provided by free air convection. Connectors include Molex 5277-02A for AC input and Molex 5273 for DC output.
90-264 VAC
48V at 2.3A (100W)
0°C to 70°C (with derating)
Open frame, chassis mount
Overvoltage (latch off), overload (auto recovery), short circuit (auto recovery)
EMI: EN55022 Class B, FCC Class B; Harmonics: EN61000-3-2 Class D; EMS immunity: EN61000-4-2, -3, -4, -5, -6, -8, -11
