The XP Power DTE1048D15 is a 10W encapsulated DC-DC converter designed for industrial and commercial applications. It offers regulated dual outputs of ±15VDC with a maximum current of 333mA per output, powered by a wide 9-36VDC input range.
This converter boasts a typical efficiency of 86% and provides 3.0kVDC isolation between input and output. It is fully protected against input undervoltage, short circuit, and overload conditions. The operating temperature range is -40°C to +105°C, with full power available up to +80°C.
Designed for easy integration, the DTE1048D15 features a chassis mount form factor and screw terminals for connection. It also includes remote On/Off control and an LED indicator for power good status. The dimensions are 79.0 x 34.0 x 22.0mm.
Compliance includes standards such as 62368-1 and approvals from CB and CE agencies, making it suitable for various ITE (Commercial) applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The XP Power DTE1048D15 provides dual ±15VDC outputs.
The input voltage range for the DTE1048D15 is 9-36 VDC for nominal 24VDC systems and 18-75 VDC for nominal 48VDC systems.
The DTE1048D15 converter has a power rating of 10W.
The typical efficiency of the DTE1048D15 is 86%.
The operating temperature range for the DTE1048D15 is -40°C to +105°C, with full power available up to +80°C.
The DTE1048D15 is a chassis mount device.
