| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
9,930 pcs
|
9930 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accessory Type | |
| Color | |
| For Use With | |
| Halogen Free | |
| Material | |
| Number of Positions | |
| Operating Temperature |
The DT4S-BT is a strain relief boot from TE Connectivity's DEUTSCH DTM series. It is designed for use with DTM 4-position connectors, providing environmental sealing and cable strain relief. The boot is made of gray PVC and is not sealable, but it offers an IP6K9K rating for high-pressure washdown environments.
It accommodates cable diameters from 0 to 11.1 mm and has a 180° cable exit angle. The operating temperature range is -29°C to 100°C. The boot is serviceable and RoHS compliant. It does not contain REACH SVHC, but is not halogen-free (contains Br or Cl > 900 ppm).
Packaged individually, each boot is supplied in a package quantity of 1. The part is EU RoHS and EU ELV compliant. Moisture sensitivity level is MSL 1 Unlimited.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.81 | $1.81 |
| 10+ | $1.64 | $1.64 |
| 25+ | $1.55 | $1.55 |
| 100+ | $1.48 | $1.48 |
| 250+ | $1.35 | $1.35 |
| 500+ | $1.32 | $1.32 |
| 1,000+ | $1.27 | $1.27 |
| 2,500+ | $1.26 | $1.26 |
| 5,000+ | $1.18 | $1.18 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The DT4S-BT is designed for use with 4-position DTM series connectors.
The boot is rated IP6K9K, providing protection against high-pressure water jets.
The boot is made of gray PVC.
The operating temperature range is -29°C to 100°C.
It accommodates cable diameters from 0 to 11.1 mm.
No, the boot is not sealable.
Yes, the boot is serviceable.
