| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
6,886 pcs
|
6886 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Automotive Grade | |
| Color | |
| Connector Type | |
| Contact Size | |
| Contact Termination | |
| Contact Type | |
| Fastening Type | |
| Halogen Free | |
| Housing Material | |
| Industrial Grade | |
| Mating Alignment Type | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature | |
| Operating Voltage | |
| Pitch | |
| Row Spacing | |
| SVHC Present | |
| UL Flammability Rating |
The TE Connectivity DT04-6P-L012 is a 6-position receptacle housing from the DEUTSCH DT series, designed for wire-to-panel connections. It features a 9.1 mm centerline pitch and a 4.45 mm row-to-row spacing, accommodating size 16 contacts with a mating pin diameter of 1.6 mm. The housing is made of PA 66 GF15 and is gray in color.
This connector is rated for 250 VDC operating voltage and a maximum contact current of 13 A. It is sealable and offers an IP6K9K and IP68 rating, making it suitable for harsh environments. The housing is polarized for correct mating and includes an integrated locking feature.
It is designed for panel mounting with a 180° cable exit angle. The housing is serviceable and does not include strain relief or terminal position assurance. It is compatible with wire and cable terminations and is intended for power circuit applications.
The DT04-6P-L012 is UL 94V-0 rated and complies with RoHS, ELV, and China RoHS regulations. It is packaged individually in a bag.
| Qty | Low | High |
|---|---|---|
| 1+ | $17.72 | $17.72 |
| 10+ | $15.36 | $15.36 |
| 25+ | $14.56 | $14.56 |
| 50+ | $14.35 | $14.35 |
| 100+ | $12.73 | $12.73 |
| 250+ | $11.93 | $11.93 |
| 400+ | $11.56 | $11.56 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The DT04-6P-L012 has 6 positions arranged in 3 rows.
The centerline pitch is 9.1 mm (0.358 inches).
The maximum contact current rating is 13 A.
The operating voltage is 250 VDC.
The connector is panel mount.
Yes, it is sealable and has an IP rating of IP6K9K and IP68.
The operating temperature range is -55°C to 125°C.
