DS30EA101SQ/NOPB The Texas Instruments DS30EA101SQ/NOPB is an adaptive cable equalizer designed for high-speed data transmission over copper cables. It supports data rates from 150 Mbps to 3.125 Gbps.
Mfr Part #:

DS30EA101SQ/NOPB

Available from 3 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments DS30EA101SQ/NOPB is an adaptive cable equalizer designed for high-speed data transmission over copper cables. It supports data rates from 150 Mbps to 3.125 Gbps.
✓ Total Stock: 23,951 pcs
$ Price Range: $9.34

DS30EA101SQ/NOPB Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Unit Electronics Co.,Limited ✓
Non-Authorised Inventory information
8,095 pcs
On Request
8095 pcs On Request 1 On Request On Request On Request On Request On Request
Smaxon Electronics ✓
Non-Authorised Inventory information
7,995 pcs
On Request
7995 pcs On Request 1 On Request On Request 13+ On Request On Request
Romaks Technologies ✓
Non-Authorised Inventory information
7,861 pcs
On Request
7861 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

DS30EA101SQ/NOPB Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Applications
Automotive Grade
Function
Industrial Grade
Input Signal
Lead Spacing
Medical Grade
Military Grade
Mounting Type
Operating Temperature
Output Signal
Power Consumption
Supplier Device Package
Supplier Package
Voltage
View Similar Products (0)

DS30EA101SQ/NOPB Description

Short technical summary and product information.

The DS30EA101SQ/NOPB from Texas Instruments is an adaptive cable equalizer optimized for equalizing data transmitted over copper cables. It operates over a wide range of data rates, from 150 Mbps to 3.125 Gbps, automatically adapting to equalize signals sent over various cable lengths.



This equalizer supports both single-ended and differential inputs, enabling signal equalization over coaxial and twisted pair cables. Key electrical specifications include a nominal operating voltage of 2.5V and a typical power consumption of 115 mW. The device operates within an industrial temperature range of -40°C to +85°C.



Packaged in a 16-WQFN (4x4 mm) form factor, the DS30EA101SQ/NOPB is suitable for surface mount applications. It features an LOS (Loss of Signal) detect and an output enable function, which can be tied together to disable the output when no input signal is present. This makes it a versatile component for applications requiring robust signal integrity over extended cable runs.

DS30EA101SQ/NOPB Quick Information

Product Type: Adaptive Cable Equalizer
Canonical Name: DS30EA101SQ/NOPB Adaptive Cable Equalizer
Subcategory: Specialized Interface ICs

DS30EA101SQ/NOPB Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

DS30EA101SQ/NOPB Estimated Pricing

Qty Low High
1+ $9.34 $9.34

Estimated market price range - modelled values for guidance only, not live distributor offers.

DS30EA101SQ/NOPB Features

  • Adaptive cable equalizer for copper cables.
  • Data rates from 150 Mbps to 3.125 Gbps.
  • Supports single-ended and differential inputs.
  • Operates at 2.5V with 115 mW typical power.
  • Industrial temperature range of -40°C to +85°C.

DS30EA101SQ/NOPB Applications

  • Equalizes signals over coaxial cables.
  • Equalizes signals over twisted pair cables.
  • Suitable for SD and HD video resolutions.
  • Used in security system applications.

DS30EA101SQ/NOPB FAQs

5 frequently asked questions generated from this part’s specifications.
What is the signaling rate of the DS30EA101SQ/NOPB?

The signaling rate ranges from 0.15 to 3.125 Gbps.

What are the input and output signal types supported?

It supports CML, LVDS, and PECL input and output signals.

What is the operating voltage for this equalizer?

The operating voltage is 2.5V.

What is the operating temperature range?

The operating temperature range is -40°C to +85°C.

What package type is the DS30EA101SQ/NOPB available in?

It is available in a 16-WQFN (4x4 mm) package for surface mounting.
