| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5,040 pcs
|
5040 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Date Format | |
| Features | |
| Interface | |
| Lead Spacing | |
| Memory Size | |
| Mounting Type | |
| Operating Temperature | |
| Supplier Device Package | |
| Supplier Package | |
| Tape & Reel | |
| Time Format | |
| Type | |
| Voltage | |
| Watchdog Timer |
The DS1553-100+ is a versatile real-time clock (RTC) and calendar IC from Analog Devices / Maxim Integrated, featuring integrated non-volatile static RAM (NV SRAM). This component is year-2000-compliant (Y2KC) and provides essential functions including an RTC alarm, watchdog timer, and power-on reset.
The device offers a byte-wide interface for accessing its registers, which store century, year, month, date, day, hours, minutes, and seconds in 24-hour BCD format. Automatic leap year compensation is included, valid up to the year 2100. The integrated NV SRAM provides 8k x 8 of memory, and the entire device is nonvolatile with over 10 years of operation expected in the absence of power.
Designed for through-hole mounting, the DS1553-100+ comes in a 28-EDIP package. It operates within a voltage range of 4.5V to 5.5V and has an operating temperature range of 0°C to 70°C. Key features include power-fail write protection, a battery voltage level indicator flag, and programmable watchdog timer and RTC alarm functions.
The operating voltage for the DS1553-100+ is between 4.5V and 5.5V.
The operating temperature range for the DS1553-100+ is 0°C to 70°C.
The DS1553-100+ is supplied in a 28-EDIP package.
The RoHS status of the DS1553-100+ is RoHS3 Compliant.
The DS1553-100+ has a memory size of 8KB.
Yes, the DS1553-100+ is Year-2000-compliant (Y2KC).
The DS1553-100+ offers an alarm, leap year compensation, NV SRAM, a watchdog timer, and Y2K compliance.
