| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
370 pcs
|
370 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Contact Plating | |
| Contact Resistance | |
| Current Rating | |
| Dielectric Withstanding Voltage | |
| Housing Material | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Contacts | |
| Pitch | |
| SVHC Present | |
| Temperature Range |
The CONNFLY DS1013-14SSiB1-B-0 is a flexible printed circuit (FPC) connector designed for reliable interconnections. This model features 14 positions with a standard pitch of 2.54mm, making it suitable for various electronic assemblies.
Key electrical characteristics include a contact resistance of 20mΩ maximum, a dielectric withstanding voltage of 500V AC(rms) for 1 minute, and an insulation resistance of 1000MΩ minimum. The connector is rated for a current of 3A.
Environmentally, the DS1013-14SSiB1-B-0 operates within a temperature range of -40°C to +105°C. It is constructed with PBT UL94 V-0 housing material and features full gold flash contact plating for enhanced conductivity and durability. The mounting type is V/T type, designed for specific PCB integration.
This connector is supplied in a standard package of 200 pieces.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch of the DS1013-14SSiB1-B-0 connector is 2.54mm.
The DS1013-14SSiB1-B-0 connector has 14 positions.
The current rating for the DS1013-14SSiB1-B-0 connector is 3A.
The operating temperature range of the DS1013-14SSiB1-B-0 connector is -40°C to +105°C.
The DS1013-14SSiB1-B-0 connector uses V/T type mounting.
The contact plating for the DS1013-14SSiB1-B-0 connector is full gold flash.
The housing material of the DS1013-14SSiB1-B-0 connector is PBT UL94 V-0.
