DRV8412DDW
Texas Instruments
The Texas Instruments DRV8412DDW is a dual H-bridge motor driver capable of up to 6A peak current. It offers high efficiency and integrated protection features.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,985 pcs
|
3985 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
3,235 pcs
|
3235 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
656 pcs
|
656 pcs | On Request | 1 | On Request | On Request | 18+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Fault Protection | |
| Features | |
| Interface | |
| Load Type | |
| Mounting Type | |
| Operating Temperature | |
| Output Configuration | |
| Rds On (Typ) | |
| SVHC Present | |
| Supplier Device Package | |
| Technology | |
| Voltage |
The Texas Instruments DRV8412DDWR is a high-performance integrated dual full-bridge motor driver. It features an advanced protection system and a high-efficiency power stage with low RDS(on) MOSFETs, achieving up to 97% efficiency. This driver is suitable for applications requiring precise control of DC and stepper motors.
Key electrical specifications include an operating supply voltage range of 0V to 52.5V and a low on-state resistance of 110mOhm. The device supports a 6A current output and utilizes a PWM interface for control. Integrated self-protection circuits include undervoltage, overtemperature, overload, and short circuit protection, enhancing reliability.
The DRV8412DDWR is housed in a 44-HTSSOP package and is designed for surface mounting. It operates within a temperature range of -40°C to 150°C (TJ). The driver is well-suited for energy-efficient applications where compact power supplies and heatsinks are desired.
| Qty | Low | High |
|---|---|---|
| 1+ | $4.65 | $4.65 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating supply voltage is up to 52.5V.
The typical Rds On is 110mOhm for both low-side and high-side MOSFETs.
The device supports a current output of 6A.
This driver is designed for DC motors and stepper motors.
It includes current limiting, over temperature, short circuit, and undervoltage lockout (UVLO) protection.
The operating temperature range is -40°C to 150°C (TJ).
It is supplied in a 44-HTSSOP package for surface mounting.
