| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AC Voltage | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Type | |
| Input Voltage (AC) | |
| Isolation Voltage | |
| Length | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Power | |
| Output Voltage | |
| Power (Watts) | |
| Standard Number | |
| Voltage | |
| Width |
The Delta Electronics DRP048V480W1BN is an AC/DC DIN Rail power supply that delivers a single output of 48V at 10A for a total of 480W. It accepts a universal AC input ranging from 85 to 264 VAC, making it suitable for global applications. The unit achieves a typical efficiency of 93%, reducing energy loss and heat generation.
This power supply includes several advanced features: adjustable output voltage, load sharing capability for parallel operation, active Power Factor Correction (PFC), and a built-in IP20 rating for indoor use. It provides 4 kV isolation between input and output, enhancing safety and noise immunity.
Designed for commercial ITE (Information Technology Equipment) applications, the DRP048V480W1BN operates over a temperature range of -25°C to 75°C with derating. The mechanical dimensions are 144.0 mm (5.67") in length, 118.6 mm (4.67") in width, and 121.0 mm (4.76") in height, allowing for installation in standard DIN rail enclosures.
Compliance with multiple international standards is confirmed, including UL 508, EN 60950-1, and EN 61010-1, among others. The unit carries approvals from UL, CE, CSA, EAC, EN, SIQ, and CB Scheme.
The output voltage is 48V.
The input voltage range is 85 to 264 VAC.
The output power is 480W.
The efficiency is 93%.
The operating temperature range is -25°C to 75°C with derating.
Yes, it is RoHS3 compliant.
It is approved by UL, CE, CSA, EAC, EN, SIQ, and CB Scheme.
